Compositor bridge

Use this socket API to build a dock, launcher or window switcher. Set persistent shortcuts in the Lua config; use bridge bindings for interactive UI while your client is connected. The bridge also lets your shell read windows and request window actions.

For terminal commands and scripts, gnoblinctl handles the connection for you.

Availability

The bridge is a built-in Gnoblin compositor service. It starts with the Gnoblin Shell component, stays available across gnoblinctl reload, and does not need to be installed under ~/.config/gnoblin/scripts/. gnoblinctl window list uses the same socket. Check gnoblinctl status before debugging a client connection.

Bingux is a separate shell project that uses this interface. A custom shell can connect to it without installing Bingux.

Bingux is one shell example built on Gnoblin's compositor interfaces.

Connect

Socket: $XDG_RUNTIME_DIR/gnoblin/compositor-v1.sock. Use GNOBLIN_COMPOSITOR_SOCKET on both ends for a private test path.

The server sends a greeting, including available features:

{ "event": "hello", "version": 1, "features": ["ui-sessions", "switcher-fallback", "overlay-shortcut"] }

Additional features depend on the running build. Send one UTF-8 JSON object per line, followed by a newline. Keep the connection open.

The hello.version field is the socket protocol version. This build always advertises ui-sessions, switcher-fallback and overlay-shortcut. It may also advertise blur-regions and layer-animation-policy when the required compositor support is available.

A validation error has an error event. If a valid command request fails, the response also carries its request id. Malformed JSON or excessive input closes the socket; ordinary validation errors leave it open.

Operation index

op	Required fields	Reply or stream
command	id, command; command-specific fields	One reply with matching id, or error
windows	None	Current windows snapshot, then changes
privacy	None	Current privacy state, then changes
status	None	One status with binding IDs and active session ID
bind	id, accelerator, hold; optional trigger, modal, captureInput	bound, then activation and input events
activate	window; optional session	Focus a window; no success reply
preview	window, width, height	One preview event
shortcut-input	name, state	Input handoff; no success reply
ui-session	action; other fields depend on action	ui-state or ui-command events
layer-animation-policy	namespace	One policy event for that layer namespace
blur-region	namespace, screen, region	No success reply
window-drag	None	Current window-drag state, then changes
snap-offer	serial, regions	No success reply; may later get snap-completed
snap-context	None	One snap-context event
snap-window	window, monitor, target	Applies a region; no success reply
stop-sharing, stop-recording	None	Requests stop; no success reply
end	Optional session for fallback switcher	Ends this client's input session
clear	None	Removes this client's bindings and session

command accepts windows, capture-windows, workspaces, workspace-list, workspace-switch, workspace-next, workspace-previous, workspace-move-active, monitors, layers and window. layers returns the current layer-shell surfaces in a surfaces array. window needs an action and a stable window ID or "active". The CLI reference lists window actions and arguments.

Workspace commands

Use workspace-list to get the workspace ID, current one-based number, display name, active state and eligible window count:

{ "op": "command", "id": "request-1", "command": "workspace-list" }

The reply's result is shaped like this:

{
    "workspaces": [
        { "id": "code", "number": 1, "name": "Code", "active": true, "windows": 2 },
        { "id": "web", "number": 2, "name": "Web", "active": false, "windows": 0 }
    ]
}

The request id correlates its reply. A configured workspace ID is assigned by its initial position and stays with that MetaWorkspace if workspaces are reordered during the session. An unconfigured workspace receives a session-only ID such as @session-N.

Each item from workspaces has these fields:

Field	Meaning
id	Configured ID, or a generated session-only ID such as @session-1.
number	Current one-based position.
name	Display label.
active	Whether this workspace is selected.
windows	Number of eligible windows on the workspace.

The older workspaces command keeps its legacy response: its numeric id is the current one-based position, and it does not include the display name.

Switch by stable ID or current number. Send exactly one selector:

{"op":"command","id":"request-2","command":"workspace-switch","workspaceId":"code"}
{"op":"command","id":"request-3","command":"workspace-switch","workspaceNumber":2}

workspace-switch also accepts a numeric workspace selector. workspace-next and workspace-previous take no selector and wrap at the ends of the current workspace list.

Switch replies contain ok, pending, and the one-based workspace number. They also include the resolved workspace's id, number, name, active, and windows fields.

Move the focused window with workspace-move-active. It accepts the same workspaceId or workspaceNumber selector, plus an optional follow boolean. The default is false; set it to true to activate the destination after moving.

For an explicit window, use command: "window", action: "workspace", and the window ID with workspaceId or workspaceNumber. The one-based numeric workspace selector is also accepted.

Successful move replies include the resolved workspace fields, follow, the stable window window ID, and the selected workspace number, workspaceId, and workspaceNumber.

Numbers can change when dynamic workspaces are removed. Use IDs in shell integrations that need to keep addressing a configured workspace. The workspace CLI examples show equivalent terminal commands.

Only command supplies a correlation ID: match reply or error by that ID because other events can arrive first. A reply with pending: true means the action was accepted; observe later state to confirm completion.

Animations are registered in Lua with gnoblin.animation and are previewed through gnoblinctl animation. Shell clients should continue to own their surface content motion; use a matching animation = "none" layer rule to avoid applying compositor motion twice.

The bridge's layer-animation-policy operation lets a shell read the configured enter/exit policy for a namespace. See the animation guide for layer-shell lifecycle events and target selection.

Capture records

capture-windows returns visible, non-minimised windows in stacking order.

Field	Meaning
id	Mutter window ID, used for capture.
title, appId, appName	Window title, desktop-entry ID and application name.
x, y, width, height	Frame rectangle in logical pixels.
bufferWidth, bufferHeight	Paint-box size; may include decoration shadows beyond the frame.

Window records

The windows snapshot has these fields:

Field	Meaning
id	Stable window sequence ID for this session.
title, appId	Window title and desktop-entry ID (or WM class if unavailable).
gtkAppId, wmClass, ruleAppId	Raw GTK ID, WM class and the ID used by window rules.
focused, minimized	Whether the window is focused or minimised.
workspace, workspaceId, workspaceNumber	Current workspace number, stable ID and current one-based position.
monitorIndex, monitor	Zero-based monitor index and its logical origin {x, y}.
maximized, fullscreen	Current window state.
geometry	Frame rectangle {x, y, width, height} in logical pixels.
lastUserTime	Mutter's timestamp for the last user interaction with the window.
parent	Stable ID of its transient parent, or null.

Capture IDs come from Mutter; windows snapshots use stable sequence IDs. Use an ID from the windows snapshot or gnoblinctl window list for a window action. The CLI reference lists the supported actions and arguments.

Example: watch the window list

Run this Python program inside your Gnoblin session:

import json
import os
import socket

path = os.environ.get("GNOBLIN_COMPOSITOR_SOCKET") or os.path.join(
    os.environ["XDG_RUNTIME_DIR"], "gnoblin/compositor-v1.sock"
)
with socket.socket(socket.AF_UNIX, socket.SOCK_STREAM) as connection:
    connection.connect(path)
    with connection.makefile("r", encoding="utf-8") as messages:
        print("Greeting:", json.loads(messages.readline()))
        connection.sendall(b'{"op":"windows"}\n')
        for line in messages:
            event = json.loads(line)
            if event.get("event") == "windows":
                print(event["windows"])

It prints the current list and subsequent snapshots as windows change. Stop it with Ctrl+C. Each snapshot replaces the previous list; it is not a list of changes.

Temporary UI bindings

Use bind for an interactive UI such as a switcher. These bindings belong to the client connection and disappear when it disconnects.

Optional trigger is "press" (the default) or "release"; it chooses whether activated is sent when the accelerator is pressed or its main key is released. This works with chords using Alt, Control, Shift or Super. Bare "Super" is release-only because Mutter first checks whether another key joins the chord.

{ "op": "bind", "id": "example", "accelerator": "<Alt>F8", "hold": 8, "trigger": "release" }

The server acknowledges:

{ "event": "bound", "id": "example" }

Field	Accepted values	Default
id	1–64 letters, numbers, _ or -; unique on this connection	Required
accelerator	GTK accelerator string up to 128 characters, or "Super"	Required
hold	0, Alt 8, Control 4, or Super 67108864	Required; 0 fires once
trigger	"press" or "release"	"press"; "Super" uses "release"
modal	Boolean	true; false leaves app input ungrabbed
captureInput	Boolean	false; enables the popup typing handoff below

For a modal held shortcut, Gnoblin captures key and pointer events before your popup becomes visible. An Alt-held switcher can finish when Alt is released.

Set modal = false for a held shortcut that should leave focus and input with the current app. Gnoblin reports the activation and modifier release without opening an input grab. For example, this reports Alt+F8 and the later Alt release while the app keeps receiving input:

{ "op": "bind", "id": "cycle-mode", "accelerator": "<Alt>F8", "hold": 8, "modal": false }

Events sent during a binding session:

Event	Fields	Meaning
activated	id, first, session, modifiers, time	The accelerator fired.
key	key, modifiers	A captured key press.
pointer	x, y, button	A captured button press in global logical pixels; 1 is left.
released, cancelled	session	The modifier was released or the session ended early.

first is true when no binding session was active. session is zero for ordinary bindings and nonzero for the built-in switcher fallback. modifiers is a Clutter modifier mask, and time is the event timestamp in milliseconds.

Hide the UI on release or cancellation. Sending {"op":"end"}, locking, disconnecting or reaching the ten-second timeout also releases the captured input.

Bare Super and buffered typing

{ "op": "bind", "id": "search", "accelerator": "Super", "hold": 0, "captureInput": true }

Requires the advertised overlay-shortcut feature. Only one bridge client can own bare Super; remove a duplicate Lua command binding first.

Super activates on release, excluding chords. With capture enabled, report the popup's focus handoff:

{ "op": "shortcut-input", "name": "search", "state": "prepared" }
{ "op": "shortcut-input", "name": "search", "state": "ready" }

Send prepared once the popup is mapped. Gnoblin releases its keyboard grab but keeps buffering keys. Send ready when the text field has focus; Gnoblin replays the buffered keys in order. Send closed when the popup is dismissed. The buffer expires after three seconds if the popup never becomes ready.

The binding ID is the handoff name.

Windows and controls

Request	Result
{"op":"windows"}	Subscribe to complete snapshots
{"op":"activate","window":"123"}	End this client's grab and focus a window
{"op":"status"}	Registered IDs and active session
{"op":"end"}	Cancel this client's input session
{"op":"clear"}	Remove this client's bindings and session

Snapshots exclude skip-taskbar and override-redirect windows. IDs last for the window's session lifetime. The client chooses grouping and ordering; stale IDs return an error. See the field list below for the complete record shape.

A subscription with no open windows produces:

{ "event": "windows", "windows": [] }

When windows exist, the array uses the window record example. See CLI development for a complete request, successful reply and error reply.

Previews

{ "op": "preview", "window": "123", "width": 224, "height": 126 }

The response contains a PNG data URI in source, dimensions and window ID. On failure it returns an empty source and a message; retain the last valid image.

Maximum size: 480 × 320, preserving aspect ratio. One capture may be pending per client. No continuous stream is started; clients choose update frequency.

Capture is unavailable while locked. Readback runs at low priority, PNG encoding uses a worker, and minimised windows use their retained buffer.

Bingux text-entry integration

Text entry is provided by a Bingux-owned integration. Bingux installs a Gnoblin script that registers the namespaced bingux.input-anchor and bingux.type-text operations. Other shells can omit the integration script and implement their own text-entry behavior.

{"op":"bingux.input-anchor"} returns x, y, pid, window, frame and caret. Coordinates are logical desktop pixels. Caret may be null; it clears on focus changes and lock, and adjusts when the window moves.

{"op":"bingux.type-text","window":"123","text":"…"} accepts up to 64 UTF-16 units, without control characters. The target must be focused and unlocked, with Control, Alt and Super released.

Hide the picker and restore the target before sending. A typed reply acknowledges delivery, not proof that the app consumed the text.

For XWayland, a GTK helper temporarily offers the text and sends Ctrl+V. It preserves clipboard formats and restores them after 600 ms unless a new copy takes priority. Clipboard managers may record the temporary text.

Clipboard preparation is limited to 64 formats, 64 MiB and three seconds. Failed preparation leaves it unchanged. Native Wayland text input does not use the clipboard.

On XWayland, Bingux uses its bingux-clipboard-paste helper, which needs Python, PyGObject and GTK 3. Native Wayland text input does not use the helper. The helper and GJS integration are shipped by Bingux. The integration script is loaded from the XDG script search path; see writing scripts.

Recording and camera activity

{"op":"privacy"} subscribes to screenSharing, recording, recordingCount, recordingElapsed, cameraInUse and locationCaptures.

Location captures list authorised GeoClue desktop IDs. Elapsed time is whole seconds; clients can advance it between updates.

stop-sharing stops non-recording remote sessions. stop-recording stops recording sessions. An encoder owner should use its normal finalisation path to save output. These requests do not grant access.

Coordinate shell processes

ui-session shares named state between UI processes. Names match ^[a-z][a-z0-9-]{0,63}$; one client owns each name.

Action	Fields	Event
watch	None	ui-state for each owner and later changes
state	name, state object	Publishes ui-state
command	name, command	Sends ui-command to the owner

watch immediately sends current owners, then updates. A state request claims or updates a name; another client cannot claim it. Owner disconnect removes its state and publishes state: null. command is forwarded to the current owner as-is; it is ignored when no owner exists and is never queued.

These requests show the message shapes; each goes over the relevant client's own bridge connection:

{"op":"ui-session","action":"watch"}
{"op":"ui-session","action":"state","name":"search","state":{"visible":true}}
{"op":"ui-session","action":"command","name":"search","command":{"action":"close"}}

The owner defines the state and command objects. To coordinate layer stacking, include surface (the owner's namespace) and companions (up to 16 namespace strings) in state. Gnoblin applies the request while visible or revealCompanions is true; set companionsAbove: true to place companions above the owner. The state is advisory and does not change how a client draws.

Operation	Fields	Limit or effect
blur-region	namespace, monitor origin screen: [x,y], local region: [x,y,width,height] or null	Up to 64 per client; requires a matching blur window rule; cleared on disconnect. See effect rendering.
layer-animation-policy	namespace	Returns enter, exit, windowShadow; namespace at most 128 characters

For blur-region:

• screen: two finite coordinates within ±65,536 for the monitor origin.
• region: null clears it. Otherwise use four finite values [x, y, width, height]; coordinates must be within ±65,536, and dimensions cannot be negative.
• Scope: Gnoblin applies the rectangle only to a matching layer surface owned by the sending process. A matching window rule must also enable blur.

For drag layouts, subscribe with window-drag, offer hit and target rectangles using snap-offer, and apply a keyboard-chosen rectangle with snap-window. The snapping guide gives the request shapes and work-area checks.

Limits and disconnects

The socket directory is private to the user. Limits: 32 clients, 32 bindings per client, 64 queued records and 4 MiB queued output per connection. An input buffer over 16 KiB or malformed JSON closes the connection. A slow reader can also be disconnected when its output queue fills.

Invalid requests return errors. Malformed JSON or excessive input disconnects the client. Disconnect releases its bindings and other resources.
